R 1 338,60 Inc VAT
R 1 164,00
Exc VAT
Flat Faced Hydraulic Coupling - Female - Body Size 3/4"
Part No.
Product Details
76216
Product Details
Flat Faced Hydraulic Coupling - Female - Body Size 3/4" - Thread Size 1" BSPP
This series of flat face couplings are known for their leak free performance across multiple applications and are the preferred choice for many global OEMs.
Body Size: 3/4"
Thread: 1" BSPP
D1: 48mm / 1.89"
L1: 99.0mm / 3.90"
A/F: 46.0mm / 1.81"
APPLICATIONS
• High pressure pulse applications
• Leak free environments
• Construction plant
• Mobile equipment
• General industrial
• Agricultural
• Skid steer loaders
FEATURES
• Safety locking sleeve fitted as standard to prevent accidental disconnection
• Flat faces are easily wiped clean
• Minimal inclusion of air and contaminants during connection
• Flat face design prevents fluid loss during disconnection
• Bidirectional flow
SPECIFICATIONS
• Carbon steel with zinc nickel plating (1200 hours with no red rust in salt spray tests)
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Couplings have been tested to the ISO 18869 Standard
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 350 bar (Flow in Litres Per Minute) - 5075 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1450 bar (Flow in Litres Per Minute) - 21025 PSI (Flow in Gallons Per Minute)
• Rated Flow - 100 bar (Flow in Litres Per Minute) - 26.4 PSI (Flow in Gallons Per Minute)
