R 3 513,25 Inc VAT
R 3 055,00
Exc VAT
Related Items(1)
Flat Faced Hydraulic Coupling - Female - Body Size 1"
Part No.
Product Details
76246
Product Details
Flat Faced Hydraulic Coupling - Female - Body Size 1" - Thread Size 1" BSPP
This series of flat face couplings are known for their leak free performance across multiple applications and are the preferred choice for many global OEMs.
Body Size: 1"
Thread: 1" BSPP
D1: 55.0mm / 2.17"
L1: 108.5mm / 4.27"
A/F: 55.0mm / 2.17"
APPLICATIONS
• High pressure pulse applications
• Leak free environments
• Construction plant
• Mobile equipment
• General industrial
• Agricultural
• Skid steer loaders
FEATURES
• Safety locking sleeve fitted as standard to prevent accidental disconnection
• Flat faces are easily wiped clean
• Minimal inclusion of air and contaminants during connection
• Flat face design prevents fluid loss during disconnection
• Bidirectional flow
SPECIFICATIONS
• Carbon steel with zinc nickel plating (1200 hours with no red rust in salt spray tests)
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Couplings have been tested to the ISO 18869 Standard
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 315 bar (Flow in Litres Per Minute) - 4568 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1000 bar (Flow in Litres Per Minute) - 14500 PSI (Flow in Gallons Per Minute)
• Rated Flow - 189 bar (Flow in Litres Per Minute) - 50 PSI (Flow in Gallons Per Minute)
