main product photo
R 3 438,50 Inc VAT R 2 990,00 Exc VAT
Grouped product items
Product Name Qty
Double Blower Motor - SPAL 30000154
R 3 438,50 Inc VAT R 2 990,00 Exc VAT
Van Available 5-10 Days
Worldwide Delivery

Our shopping cart does its best to calculate the most accurate carriage cost for your order. The carriage is calculated based on the combined weight of the goods followed by the addition of product-related surcharges. Visit our Delivery Information Page for more information.

Worldwide Delivery
Save
Get Help Here Need some help? Click here to contact us

Double Blower Motor - SPAL 30000154 suitable for Case International - 134684473 134684033

Part No.

Product Details

75393

Product Details

Overall Length: 351mm.
Overall Height: 140mm.
Overall Width: 168mm.
Mounting Base Length: 351mm.
Mounting Base Width: 136mm.

12v.
Double Blower Wheel.
537 CFM.
17.2A Current Draw.
3 Speeds. Aluminium Resistor Supplied.
Jumper Between Electric Motor And Resistor (No Wire Harness Included).

Maximum Airflow (At Zero Static Pressure): 537FM (910m³/h).
Standard Features: Long Life.
Operating Voltage: 12v.
IP Rating: IP30.
SPAL Type / Description: 006-A46-22 GR RA3VCV.
GR: Grid.
RA: Aluminium Resistor.
3V: 3 Speeds.
CV: Jumper Between Electric Motor And Resistor (Without Wire Harness).
Mounting Bolt/Screw: M4 Screw.
Mounting Torque: 3(+1/-0) Nm.
Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001.

Suitable For - Case International models , CS100, CS110, CS120, CS130, CS150, CS75, CS78, CS80, CS86, CS90, CS94, CVX120, CVX130, CVX150, CVX170, CVX1135, CVX1145, CVX1155, CVX1170, CVX1190, CVX1195 for OEM's 134684473, 134684033

Fits Models

Product OEM
